H685 5G Router

The H685 5G Router is a compact, industrial grade 5G router with embedded high speed 5G modem to deliver high speed 5G Mobile Broadband Internet connectivity for M2M remote monitoring and management applications that need the convenience of mobile broadband Internet with the high download and upload speeds offered by 5G mobile networks in the UK.

Proroute H685 5G Router

The Proroute H685 5G Router builds upon the success of the Proroute H685 4G Router and provides all the sames features but with high speed 5G connectivity.  This router has a compact design with the robust casing measuring just 100mm x 60mm x 23mm and provides LAN connectivity via 2 x Ethernet Ports and also includes WiFi for extra connectivity.

This router is ideal for M2M route access, monitoring and management applications that require a reliable, secure and high speed 4G or 5G Internet connection such as remote access and viewing of CCTV installations.

Conveniently, Unlimited Fixed IP SIM cards have become available in the UK which means that you can now use large amounts of 4G and 5G data with the H685 5G router making the combination of H685 and unlimited SIM card with static IP address the ideal choice for CCTV installers.

Unlimited Data Static IP SIM

The Proroute H685 5G Router is an ideal product for industrial applications owing to its small form factor, feature set and tough construction. H685 is designed to support any high speed mobile broadband applications in M2M, CCTV, Security, Media, Utilities and any other area that requires IP connectivity between a device and a host on the internet. The device can be used with Fixed IP SIMs or normal data SIMs. It also supports Dynamic DNS where it is possible to use this across the operators network.

Mobile data communications using embedded Routers is fast becoming an essential tool for providers field based communications solutions. The Proroute H685 5G Router is designed to stay on line and connected, it has various stay-alive features giving you peace of mind with remote site communications, particularly CCTV and Telemetry.

The Proroute H685 provides high capacity 5G connection whilst maintaining a reliable, secure and discrete communications service. H685 provides an excellent technical capability whilst still offering a commercially proposition so far not seen in the market compared to other products in this field.

The Proroute H685 5G Router is supplied with stick type antennas shown in the pictures. The H685 Router has 2 x WiFi antenna connection and 4 x Cell antenna connection.

The WAN port of the Proroute H685 5G router can be configured to operate as a LAN port, thus providing the ability to connect two wired devices if required.

Proroute H685 Features

– Industrial, robust construction
– Small and easy to install
– Ideal for remote unmanned applications
– Easy to set up and will work out of the box in simple installs i.e. internet access only.
– Supports external antennas so ideal for remote and low signal strength areas.
– Embedded 5G modem RM500Q:
——- Downlink data: 5G/NR NSA sub-6: 2.5Gbps, LTE 1Gbps
——- Uplink data: 5G/NR sub-6:600Mbps, LTE 200Mbps
——- NB: the bandwidth is peak value. Real value depends on carrier network support.
– Keep alive features utilising PING and SMS
– High Speed WiFi – 802.11a/b/g/n – Can be used as AP and client;
– Port forwarding facilities for efficient data transfer and connection to multiple devices as well as remote admin.
– Discrete and robust – does not look like an office product so less likely to be interfered with.
– Wide voltage range for industrial applications
– VPN and security functions of normal business router within a secure corporate network


Hardware CPU: 880Mhz dual core;
RAM: 1Gb DDR3, option for up to 4Gb DDR3;
Flash: 128Mb, option for up to 8Gbit;
WAN Integrated Category 5G modem (with 4G LTE /3G failover);
One 10/100/1000Mbps Gigabit Ethernet ports – cable/DSL/T1/satellite/Metro Ethernet;
WiFi as WAN, Metro WiFi; MIMO “N” 2.4 GHz; 802.11 a/b/g/n;
LAN WiFi; 802.11 a/b/g/n
2 LAN/WAN switchable 10/100/1000Mbps Gigabit Ethernet ports;
Ports Power (DC Jack, 2 Pin Terminal Block for wire connection)
2 Ethernet LAN/WAN
2-4 cellular antenna connectors (SMA)
1 GPS/Beidou antenna connector (SMA)
2 WiFi antenna connectors (SMA)
Serial connector – RS232 / RS485 (Terminal Socket)
4 Digital I/O ports (Terminal Socket)
Console Port (Terminal Socket)
Power Dual Power Inputs / Power Failover;
DC input steady state voltage range: 5-40 VDC / 5-60VDC option, (requires inline fuse for vehicle installations)
For 9-24 VDC installations, use a 3 A fuse;
For greater than 24 VDC installations, use a 2.5 A fuse;
Reverse polarity and transient voltage protection per ISO 7637-2
Ignition sensing (automatic ON and time-delay OFF);
Power consumption:
Idle: typical=100mA@12VDC; Maximum=500mA@12VDC;
Tx/Rx: typical=300mA@12VDC; Maximum=800mA@12VDC;
12VDC 2A adapter recommended
LEDs SYS*1, VPN (IPSec)*1, Cell Signal*1, Cell*1, WAN*1, LAN*1, WiFi*1
UIM/SIM Card Slot Support 1.8V/3V UIM/SIM cards
Others Reset button, console port,
Size PCBA: 96mm x 56mm x 14mm
With case: 100mm x 60mm x 21mm
Weight 230g (not including the antenna)
380g (including the antenna)
860g (including all accessories, without package)
Temperature All models: -35 °C to 75 °C ambient air operating;
All models: -40 °C to 85 °C storage;
(non-condensing) 5% to 95% operating
5% to 95% storage
Case Metal Gray-Black
Compatible Mobile Networks

5G (SA and NSA)

Cellular Frequency 5G Sub-6G:

Band 1 – 2100Mhz
Band 2 – 1900Mhz
Band 3 -1800Mhz
Band 4 – AWS(1700/2100Mhz)
Band 5 – 850Mhz
Band 7 – 2600MHz
Band 8 – 900Mhz
Band 9 – 1700Mhz
Band 12 – 700Mhz
Band 13 – 700Mhz
Band 14 – 700Mhz
Band 17 – 700Mhz
Band 20 – 800Mhz
Band 25 – 1900Mhz G Block
Band 26 – 850Mhz
Band 28 – 700Mhz
Band 30 – 2300Mhz
Band 32 – 1500Mhz (SDL)
Band 71 – 600Mhz
And other more FDD band

Band 48 – 3600Mhz (CBRS)
Band 46 – 5200Mhz
Band 43 – 3700Mhz
Band 42 – 3500Mhz (CBRS)
Band 41 – 2500/2600Mhz
Band 40 – 2300Mhz
Band 39 – 1900Mhz
Band 38 – 2600Mhz
And other more TDD band

WCDMA: B1/B2/B3/B4/B5/B8/B9/B19

2100MHz(B1)/1900MHz (B2)/1800MHz (B3)/ 1700MHz /AWS (B4)/850MHz (B5)/900MHz (B8)/800MHz (B6)/1800MHz (B9)/850MHz (B19)

Notes: the bandwidth is peak value. Real value depends on carrier network support.
Network and Band Lock Feature (Option) Default is unlocked, can use this feature to lock
Wi-Fi 802.11a/b/g/n;
Can be used as AP and client;

Frequency Range:
2.4Ghz: 2.412 ~ 2.472Ghz
5Ghz Band 1: 5150~5250MHz
5Ghz Band 4: 5475~5850MHz

802.11n in 300Mbps;
802.11AC options in 867Mbps;

Minimum System Requirements Windows, Linux, Mac OS, IOS, Symbian, Android, other OS support web browser;
Warranty 1 Year default.
Package Contents H685 Series 5G Router
Ethernet Cable
Power Adapter
Cellular Antenna, WiFi Antenna
